Casing:High-quality galvanized steel with powder coating, excellent corrosion resistance; side panels secured with screws for tight sealing.
Double Water Pan:Angled diamond outer pan for smooth, residue-free drainage; aluminum trough inner pan.
Coils:Ø9.52mm internally grooved copper tubes, 36×31.18 inverted delta arrangement for large heat transfer area and small temperature difference.
Fins:Hydrophilic corrugated aluminum fins with 4.5mm, 6.0mm, and 9.0mm fin spacing to meet various temperature and humidity requirements.
Submit project requirements and available documentation for review.
